Designation:

AMSTAF 6

Info
Manufacturer: Automotive Robotic Industry - ARI
Product type: Auxiliary Vehicles
Name: Robot, Unmanned Vehicle

AMSTAF 6 General Information

  • Autonomous and collaborative UGV, designed to perform security, safety and rescue missions

  • Always on guard, acts as Commander’s eyes on the scene and first responder

  • Multi-functional platform for a wide range of payload, based on the ODG “ARGO” 6X6 and 8X8 platforms

  • Multi-mission – Patrol, Observe, Scout, Track, Go to point, Respond, Pursue

  • Multi-task – Can carry riot control, weaponry, surveillances, fire-extinguishing, CBRN detection and containment systems and cargo

  • Multi-sensor Platforms – Positioning, Mapping, Path Planning, Obstacle detection and avoidance capabilities with operation safety

  • All Terrain and Amphibious – will cross swamps and snow

  • Operates in almost all weather conditions (-40°C to +40°C)

  • Speed up to 20Km/h on manually drive and 10-15Km/h on Autonomous missions

  • Climbing capability – maximum slope 45°

  • Up to 48 hours of continuous operation (combining battery and generartor)

  • Silent operation mode (Up to 6 hours continues)

  • Easy to control with a simple user interface

  • Economic and efficient with low maintenance

Standart Specifications

  • A 6×6 ODG “ARGO” chassis, Steel channel construction, Polyester powder coated for lasting protection

  • Body – Vacuum formed High Molecular Aerial Density Polyethylene

  • 2 Electric motors

  • Generator – optional diesel or petrol

  • Steering – Skid steered continuous torque to all axles

  • Laser Measurement System – 270˚/20m

  • High precision digital G.P.S system

  • 4 Day/Night vision Fixed wide angel Cameras – for 360˚ view

  • Day/Night vision Research Camera – (P.T.Z) with parallel (IR) led spotlight

  • Audio System – Microphone and loudspeaker

  • Safety – Remote controlled kill switch using separate communication system

  • 2 Spot-lights

Control station includes

  • Two x 22 inch touch screens

  • Operator control software with graphical user Interface

  • Tough-book laptop (for close control)

  • Gamepad remote control

  • UPS power unit for backup

  • Communication system includes

Base-station

  • mobile unit – R.F. 2.4 GHz, up to 13Km range (LOS)

  • Optional cellular system for back up

Specifications:
Property Value
Weight (kg)
1100
Payload (kg)
350
Height (mm)
850
Length (mm)
2480
Width (mm)
1480
Ground clearance (mm)
240
Fuel capacity (l)
54
Number of drive wheels
6
Number of wheels
6
Max. road speed (km/h)
20
Time of continuous operation (hours)
48
Distance of remote control (m)
13000
Engine power output (h.p.)
23
Time of continuous operation (hours)
16
