| Designation: |
ACV RV |
 |
| Manufactured by: |
|
|
| Type: |
|
|
| Name: |
|
|
|
|
| |
|
Specifications |
|
Property |
Value |
| Main weapon caliber (mm) |
12.7 |
| Max. road speed (km/h) |
65 |
| Max. swim speed (km/h) |
6.3 |
| Max. road range (km) |
490 |
| Gradient (%) |
60 |
| Side slope (%) |
30 |
| Vertical obstance (mm) |
740 |
| Trench (mm) |
1830 |
| Engine power output (h.p.) |
350 |
| Crew |
3 |
| Weight (kg) |
13900 |
| Length (mm) |
5260 |
| Height (mm) |
3120 |
| Width (mm) |
2820 |
| Height to hull top (mm) |
2010 |
| Ground clearance (mm) |
430 |
|
|
Has folowing part: |
Part |
Amount |
|
6V53TA (Diesel engine) |
1 |
|
X200-4B (Transmission) |
1 |
|
|
|
|
| |
|
|
| |
