Designation:

T-54

Info
Manufacturer: JSC Research and production corporation UralVagonZavod
Product type: Armoured Vehicles
Name: Main battle tank

Specifications:
Property Value
Crew
4
Weight (kg)
36000
Length (mm)
9000
Width (mm)
3270
Height (mm)
2400
Track (mm)
2640
Max. road speed (km/h)
50
Max. road range (km)
510
Depth of fording, without preparation (mm)
1400
Fording depth (mm)
5000
Gradient (%)
60
Vertical obstacle (mm)
800
Trench (mm)
2700
Engine power output (h.p.)
520
Number of forward gears
5
Number of reverse gears
1
Main weapon caliber (mm)
100
AA gun caliber (mm)
12.7
Auxiliary gun calibre (mm)
7.62
Ammunition of the main gun
34
Ammunition of AA gun
500
Ammunition of the auxiliary gun
3000
Elevation (degree)
17
Depression (degree)
-5
Planes of gun stabilization
0
Turret protection, max (mm)
203
Hull protection, max (mm)
98


Has folowing part:
Total Amount
54.02.1sb-6V (Water radiator)
1
54.03.4sb-3 (Oil radiator)
1
? (Track chain with rubber-padded shoes)
2
D-10 (Gun)
1
