Designation:

VN4

Info
Manufacturer: NORINCO - China North Industries Group Corporation - CNGC
Product type: Armoured Vehicles
Name: Wheeled armoured personnel carrier

VN4 4x4 wheeled armoured vehicle is a multi-role light armoured vehicle platform that can be applicable to rapid reaction forces, armoured troops, police force and also for peacekeeping and anti-terrorism missions. The vehicle can be equipped with different armament for different combat applications.

Features

  • high mobilty, the max road speed is up to 115 km/h, and with independent suspension, the vehicle possess strong cross country capability

  • good protection,the hull is close welded with armour plate, protecting the crew from small arm fires and shell splinters

  • better environment adaptability, excellent performance in tropical, desert and plateau area

  • comfortable inner space with air conditioning system

Options

  • communication system

  • CTIS (central tyre infation system)

  • driver night vision device

  • GPS

  • NBC protection system

Specifications:
Property Value
Number of wheels
4
Number of drive wheels
4
Crew
2
Troops
8
Power-to-weight ratio (h.p./t)
24.5
Length (mm)
5400
Width (mm)
2400
Height (mm)
2050
Ground clearance (mm)
380
Max. road speed (km/h)
115
Max. road range (km)
700
Trench (mm)
800
Vertical obstacle (mm)
400
Main weapon caliber (mm)
12.7
Ammunition of the main gun
840
Engine power output (h.p.)
235
Weight (kg)
5700



VN4 quantities:
Country Qnt
KENYA KENYA
30
VENEZUELA VENEZUELA
194
Qnt:
224
