Designation:

Typhoon 6x6

Info
Manufacturer: Streit Manufacturing Inc.
Product type: Auxiliary Vehicles
Name: Mine protected carrier

STREIT Groupís Typhoon 6x6 designed to provide maximum operational flexibility and protection. The vehicle has capacity to transfer up to 10 soldiers as well as a commander and a driver and can be fitted with additional remotely operated weapon system, turrets, smoke grenade launchers and communications systems. Typhoon 6x6 is fully armored to provide maximum ballistic and mine blast protection and is able to withstand ballistic threats, as well as land mine and Improvised Explosive Device (IED) attacks due to precisely designed V shaped hull and increased protection from add on armor. Vehicles components such as suspension, brake systems are built and tested to ensure they support the full armor weight including a full payload. The high capacity wheel and tire assembly comprise of built-in run-flats and bead lock systems. The vehicle interior can be fully customized to specific requirements which include jump seats, benches and individual bucket seats which protect personnel from under vehicle body blasts as well as during high speed off-road maneuvers. The vehicle is capable of operating in temperatures ranging from -20 C to + 55 C.

Applications:

  • Home Land Security

  • Counter Terror

  • Border Patrol

  • Law Enforcement

Specifications:
Property Value
Number of wheels
6
Number of drive wheels
6
Engine power output (h.p.)
400
Number of cylinders
6
Engine cylinder volume (l)
8.9
Troops
10
Crew
2
Wheelbase (mm)
3690
Width (mm)
2480
Length (mm)
8100
Height (mm)
2875
