Designation:

ACV-30

Info
Manufacturer: FNSS Defence Systems Inc
Product type: Armoured Vehicles
Name: Anti-aircraft system

The ACV30 (Medium Weight) platform is the general name for the 20-30 ton class modern high performance family of vehicles, derived from the highly successful FNSS ACV15 and ACV19. The ACV30 vehicle has a greater suspension capacity and improved power pack performance offering significant more power capacity than ACV 15 and ACV 19. This additional performance means that the ACV30 platform is able to carry significant higher payloads which include weapon stations mounting 105 mm guns and heavy air defence systems. ACV30 platform chassis is provided with a unique, space laminated armor system combining steel and aluminium technology to provide a high level of armor protection against direct KE threats. Also, the hull provides protection against mines. The vehicle configuration(s) can be tailored in accordance with customer operational requirements into a true family of vehicles which can be utilized by cavalry, infantry, MBTs support vehicles and artillery.

Specifications:
Property Value
Engine power output (h.p.)
600
Crew
3
Weight (kg)
29500
Length (mm)
7070
Width (mm)
3900
Height to hull top (mm)
2200
Height (mm)
3620
Max. road speed (km/h)
65
Max. water speed (km/h)
6
Max. road range (km)
500
Gradient (%)
60
Side slope (%)
30
Vertical obstacle (mm)
900
Power-to-weight ratio (h.p./t)
20
