Designation:

Puma 6x6

Info
Manufactured by: Consorzio Iveco Fiat Oto Melara
Type: Armoured Vehicles
Name: Wheeled armoured personnel carrier



The Defence Vehicles Division of IVECO developed the Puma family of 4 x 4 and 6 x 6 light armoured vehicles to meet the requirements of the Italian Army.

After extensive trials with prototype vehicles, the army placed a contract with IVECO in 1999 covering the supply of 540 Puma vehicles. The first vehicles were completed in 2003.

Of the 540 vehicles, 320 will be in the 6x6 version with the remaining 220 in the 4 x 4 configuration. The 6x6 version of the Puma will typically be used in the armoured personnel carrier (APC) role, while the 4 x 4 version will typically be used for reconnaissance.

To reduce overall life-cycle costs, the Puma family shares many common components, such as the diesel engine, automatic transmission and suspension.

The baseline APC version of the Puma is armed with a 12.7mm M2 machine gun. However, the vehicles can be fitted with a range of turrets and cupolas developed by Oto Melara, including one with a remote-controlled weapon.

IVECO has developed a number of specialised versions of the Puma for the Italian Army. These include ambulance, command post, 81mm mortar, air defence with MBDA Mistral missiles and two anti-tank (one with the Raytheon TOW and one with the Euromissile MILAN anti-tank guided missile system).

The Puma design is such that it can be adopted for a wide range of other roles and missions. Standard equipment includes powered steering, run-flat tyres, a nuclear, biological and chemical defensive system and afire-detection and -suppression system.

Specifications
Property
Value
Height (mm)
1900
Depth of fording, without preparation (mm)
1000
Gradient (%)
60
Troops
8
Length (mm)
5526
Main weapon caliber (mm)
7.62
Track (mm)
1945
Number of drive wheels
6
Number of wheels
6
Number of forward gears
5
Number of reverse gears
1
Max. road speed (km/h)
100
Weight (kg)
8000
Engine power output (h.p.)
180
Width (mm)
2284
Crew
1


Has folowing part:
Part
Amount
4V (Diesel engine)
1
HSWL 284C (Transmission)
1
Protector RWS (Remote controlled weapon station)
1
Reko 606 (Transmission)
1
TOW 2 BGM-71D (Anti-tank guided missile launcher)
1
Type 8042 TCA (Diesel engine)
1

Puma 6x6 Quantities:
Country
Quantity
ITALY ITALY
450
Total:
450

Puma 6x6
Puma 6x6
Puma 6x6
Puma 6x6
Puma 6x6
Puma 6x6
Puma 6x6
Puma 6x6
Puma 6x6
