Designation:

CS/VN3

Info
Manufacturer: Poly Technologies, Inc.
Product type: Armoured Vehicles
Name: Wheeled armoured personnel carrier

The CS/VN3 is a fighting vehicle for rapid deployment and emergency operations. It features light weight, small size, fast speed and high mobility. The CS/VN3 can perform tasks such as combat assaults, fire support, personnel transport and patrols, and is especially suitable for operations in complicated urban and hilly areas.

Specifications:
Property Value
Number of wheels
4
Number of drive wheels
4
Weight (kg)
8700
Length (mm)
5700
Width (mm)
2500
Height (mm)
2000
Wheelbase (mm)
3350
Ground clearance (mm)
400
Max. road range (km)
600
Fuel capacity (l)
160
Trench (mm)
650
Gradient (%)
60
Vertical obstacle (mm)
350
Turning circle radius (mm)
9000
Max. road speed (km/h)
100
Max. water speed (km/h)
6
Engine power output (h.p.)
210
Maximum torque (Nm)
700



CS/VN3 quantities:
Country Qnt
BELARUS BELARUS
10
Qnt:
10
