Designation:

FOX

Info
Manufacturer: Zetor Engineering, s.r.o.
Product type: Auxiliary Vehicles
Name: Patrol Vehicle

RAPID DEPLOYMENT VEHICLE DESIGN FAMILY

The FOX is a RDV (Rapid Deployment Vehicle) with excellent off-road performance intended for the needs of special forces or rapid deployment forces. The vehicle transports a four-member crew and equipment, including armaments.

EQUIPMENT AND ARMAMENTS

  • Main vehicle weapon mounted in the turret - 12.7 mm heavy machine gun

  • Four 7.62 mm or 5.56 mm universal machine guns

  • Possibility to mount an ATGM launcher in the turret

  • Transport of ammunition for mounted weapons and crew´s personal weapons

  • Winch

  • Front safety frame

  • Engine protection cover

  • Adjustable rope cutter

  • Crew safety seats VSS

  • Removable windscreen

  • Covering canvas for trasnport on roads out of combat deployment

  • Tilting seat in vehicle body for rear gunner

  • Tilting luggage carriers on body sides

Specifications:
Property Value
Number of wheels
4
Number of drive wheels
4
Cylinder bore (mm)
83
Cylinder stroke (mm)
92
Engine power output (h.p.)
183
Maximum torque (Nm)
400
Weight (kg)
4550
Payload (kg)
1180
Max. road speed (km/h)
120
Fuel capacity (l)
96
Vertical obstacle (mm)
245
Fording depth (mm)
600
Length (mm)
5331
Height (mm)
2594
Height to hull top (mm)
2027
Main weapon caliber (mm)
12.7
