Designation:

UW2

Info
Manufacturer: NORINCO - China North Industries Group Corporation - CNGC
Product type: Turrets
Name: Remote controlled weapon station

UW2 remote weapon station is equipped with 12.7x99mm machine gun and 40mm automatic grenade launcher which combines direct fire strike and curved-trajectory attack perfectly. It provides both point strike and area destruction functions and is suitable for urban or field low-intensity operations during anti-riot, counter-terrorism, survey and border patrol missions.

UW2 light weight remote weapon station is comprised of fire power subsystem, fire control system and platform subsystem. It is capable of direct strike against light-armored targets within 1500m and indirect attack on simple fortifications and effectiveness within 2200m. UW2 remote weapon station can be mounted on various types of lightweight armoured vehicles and has the advantage of fire on-the-move thanks to the bi-axis image-stabilized fire control system.

Features

  • Strong fire power

  • Has advantages of large elevation angle, day-night target detection, recognition, tracking and aiming, and firing on-the-move

  • Capable of in-vehicle ammunition replenishment

  • With modular structure, components and functions can be added or reduced as per operational needs

  • Compatible with various types of armoured vehicles

Specifications:
Property Value
Weight (kg)
500
Height (mm)
800
Main weapon caliber (mm)
12.7
Grenade launcher calibre (mm)
40
Ammunition of the main gun
200
Ammunition of the grenade launcher
40
Traverse arc (degree)
360
Elevation (degree)
50
Depression (degree)
-10
Firing range (m)
1500
Planes of gun stabilization
2
Slew rates in Azimuth (deg/sec)
45
Slew rates in Elevation (deg/sec)
45
